1,500 W
Brushless motor

120 kilometers
Maximum range

25 km/h
Top speed

750 WH
Replaceable battery

120 kilograms
Maximum load

20x4''
Thick tires
Top Speed and Performance (EU Version)
While a detail for more information.












Removable battery
The removable 48V 15A battery offers a range of 65–120 km with pedal assistance. For convenient charging, you can simply remove the battery and use the integrated USB port as a mobile power source on the go.


POWERFUL ENGINE
The brushless hub motor with 1,500 W peak power can reach speeds of up to 45 km/h and handle inclines of up to 35 degrees, ideal for hilly terrain.


SUSPENSION
The 6-stage full suspension, including a hydraulic aluminum suspension fork and a dual-spring rear suspension, provides a smooth and comfortable ride on varied terrain.


FENDER
The mudguard protects you and your bike from dirt and splashes, ensuring a cleaner and more comfortable ride in different weather conditions.


DISC BRAKE
With mechanical disc brakes front and rear and an EABS system, you get improved control and powerful braking on any terrain. The mechanical disc brakes provide strong and reliable stopping power, while the EABS system ensures smooth and efficient braking for a comfortable ride.


THICK TIRES
The 20" x 4.0 tires offer excellent traction and stability on a variety of surfaces and, combined with mechanical disc brakes at the front and rear, ensure reliable stopping power.


INTELLIGENT LCD DISPLAY
The smart LCD display is easy to read and shows important riding data such as speed, mileage, remaining power, and riding modes. The LCD display controller, horn, and lights conveniently located on the left side allow you to effortlessly switch between pedal-assist modes and monitor your current speed, remaining battery range, and more.


FRONT FORK SUSPENSION
The dual alloy fork shock absorbers ensure a smooth and comfortable ride by effectively absorbing shocks and vibrations. Riding'times boasts one of the best shock absorbers on the market, meticulously crafted with 100% CNC machining for unmatched precision.


SHIMANO 7-SPEED GEARBOX
With SHIMANO's 7-speed transmission, you can tackle any terrain efficiently and effortlessly. By using the right-side twist throttle and the 7-speed shift lever, you can seamlessly adjust your speed in electric, non-electric, and assist modes. Switch between riding modes to reach speeds of up to 28 mph in electric-only mode.
Urban Freedom Redefined
GEOMETRY


Seat tube 440
Head tube 170
Horizontal top tube length 590
Wheelbase 1154.4
Seat angle 72.4
Bottom bracket height to hub center 50
Head tube angle 69
Range 421
Chainstays 457
Stack height 659.8
Components
Model | Z8 | Z8 Pro |
---|---|---|
Motor |
Rear wheel hub motor 750 W |
|
Batteries | Single battery support - 48 V 15.6 Ah | 31.2 Ah double battery (2 x 48 V 15.6 Ah) |
Maximum speed | 45 km/h | |
E-bike class | Multi-class 1-3 with speed limit setting | |
Charger | 48V 2A*1 | 48V 2A*2 |
Brake system | Front and rear mechanical disc brakes | |
Range (Electric/Assisted) | 65/120 kilometers | 210/240 kilometers |
Suspension | Front fork & rear double springs | |
Display | LED color digital display | |
Weight (with battery) | 36 (42.50) kg | 36 (48.50) kg |
Tires | Sponge tire construction (front 26 x 4.0 and rear 20 x 4.0) |
